BRAIN 17 7 732788 - Rev. A_1
ENGLISH
LCD Signalling/Programming display
SW1 “+/R1” Programming button
SW2 “-/R2” Programming button
SW3 “F” Programming button
DL1 “FCC2” Input status control LED
DL2 “FCA2” Input status control LED
DL3 “FCC1” Input status control LED
DL4 “FCA1” Input status control LED
DL5 “FSW OP” Input status control LED
DL6 “FSW CL” Input status control LED
DL7 “STOP” Input status control LED
DL8 “OP-B” Input status control LED
DL9 “OP-A” Input status control LED
DL10 “
USB
” Signalling LED
DL11 “
RADIO1
” Signalling LED
DL12 “
RADIO2
” Signalling LED
DL13 “
ERROR
” Error/alarm signalling LED
DL14
“BUS MON” BUS G-WAY
diagnostic signalling
LED
DL15 Device signalling LED to
BUS G-WAY ACTIVE
DL16 Microprocessor power presence LED
DL17
+24V
"
Accessories power supply presence
LED
J1 230V~ Power supply connector
J2
Motors and flashing lamp power supply
connector
J3 Input/Output connector
J5
RQFZ433/RQFZ868 receiver module con-
nector
Channel 1
-
OPEN A
(Total Opening)
Channel 2
-
OPEN B
(Partial Opening)
J6 Limit switch input connector
J8
HOST USB-A
for Mass Memories connector
J10
BUS G-WAY
device connector
J11
W.L. (programmable) and Electric lock
(LOCK) output connector
F1 Motor and power supply safety fuse
