FRANÇAIS
Tab. 3/g
LOGIQUE “B IMPULSIONS
ÉTAT PORTAIL OPEN-A (ouverture) OPEN-B (fermeture) STOP SÉCURITÉS OUVERTURE SÉCURITÉS FERMETURE SÉCURITÉ OUV/FERM SÉCURITÉ BORD
FERMÉ Ouvre le vantail Aucun effet Aucun effet (OPEN-A inhibé)
Aucun effet (OPEN-B
inhibé)
Aucun effet (OPEN-A
inhibé)
Aucun effet (OPEN-A/B
inhibés)
OUVERT Aucun effet Ferme le vantail
Aucun effet (OPEN-B
inhibé)
Aucun effet (OPEN-A
inhibé)
Aucun effet (OPEN-B
inhibé)
EN FERMETURE Intervertit en ouverture
Aucun effet Bloque le fonctionnement
Aucun effet
Bloque le fonctionnement
(OPEN-B inhibé)
Bloque le fonctionnement
(OPEN-A/B inhibés)
Invertit en ouverture pen-
dant 2”
EN OUVERTURE Aucun effet
Bloque le fonctionnement
(OPEN-A inhibé)
Aucun effet
Invertit en fermeture pen-
dant 2”
BLOQUÉ Ouvre le vantail Ferme le vantail
Aucun effet (OPEN-A/B
inhibés)
Aucun effet (OPEN-A
inhibé)
Aucun effet (OPEN-B
inhibé)
Aucun effet (OPEN-A/B inhibés)
Tab. 3/h
LOGIQUE “BC”
IMPULSIONS EN OUVERTURE / COMMANDES TOUJOURS
ENFONCEES EN FERMETURE
IMPULSIONS
ÉTAT PORTAIL OPEN-A (ouverture) OPEN-B (fermeture) STOP SÉCURITÉS OUVERTURE SÉCURITÉS FERMETURE SÉCURITÉ OUV/FERM SÉCURITÉ BORD
FERMÉ Ouvre le vantail Aucun effet Aucun effet (OPEN-A inhibé) Aucun effet Aucun effet (OPEN-A inhibé)
OUVERT Aucun effet Ferme le vantail
Aucun effet (OPEN-B
inhibé)
Aucun effet Aucun effet (OPEN-B inhibé)
Aucun effet (OPEN A/B
inhibés)
EN FERMETURE Intervertit en ouverture Aucun effet
Bloque le fonctionnement
Aucun effet (mémorise
OPEN A)
Bloque le fonctionnement
(OPEN-B inhibé)
Aucun effet (OPEN-B
inhibé)
Invertit en ouverture pen-
dant 2”
EN OUVERTURE Aucun effet
Bloque le fonctionnement
(OPEN-A inhibé)
Aucun effet
Invertit en fermeture pen-
dant 2”
BLOQUÉ Ouvre le vantail Ferme le vantail
Aucun effet (OPEN-A/B
inhibés)
Aucun effet (OPEN-A
inhibé)
Aucun effet (OPEN-B
inhibé)
Aucun effet (OPEN-A/B inhibés)
Si maintenu, il prolonge la pause jusqu’à la désactivation de la commande (fonction temporisateur)
En cas d’une nouvelle impulsion avant l’écoulement des deux secondes d’inversion il bloque immédiatement le fonctionnement.
Entre parenthèses les effets sur les autres entrées à impulsion active.
