Fitting the inner door
Fitting the inner door
Inner door
REMOVAL OF COVER
EXPOSES HIGH VOLTAGE
REMOVE ONLY
DURING COMMISSIONING
Earth lead from
back box - inner door
Cover to protect PCB
display and keyboard
Back box
Ribbon cable
and clamp
Back box
Inner
door
CAUTION
Ensure correct fuses
are fitted
Ferrite Core
Cable and clamp
are fitted during
commissioning
