35
Vigilon COMPACT fire system
On completion of panel installation
On completion of cable installation ensure the earth lead between the backbox and
inner door is fi tted. Also the inner and outer doors are closed.
a. Close the inner door using a screw driver.
b. Fit the outer door on to the main enclosure.
c. Close and lock the outer door.
Outer
door
Backbox
