GeoMax ZONE20 H User Manual

Table of Contents Zone20 H | 3
Table of Contents
In this manual Chapter Page
1 Safety Directions
4
1.1 General 4
1.2 Definition of Use 4
1.3 Limits of Use 5
1.4 Responsibilities 5
1.5 Hazards of Use 5
1.6 Laser Classification 6
1.6.1 General 6
1.6.2 Zone20 H 7
1.7 Electromagnetic Compatibility EMC 7
1.8 FCC Statement, Applicable in U.S. 8
2 Description of the System
10
2.1 System Components 10
2.2 Zone20 H Laser Components 10
2.3 Case Components 11
2.4 Setup 11
3 Operation
12
3.1 Buttons 12
3.2 LED Indicators 12
3.3 Turning the Zone20 H on and off 13
3.4 Automatic Mode 13
3.5 Manual Mode 13
3.6 Elevation Alert (H.I.) Function 14
4 Receivers
15
4.1 ZRB35 Receiver 15
4.2 ZRP105 Receiver 16
4.3 ZRD105, Digital Receiver 17
5 Applications
19
5.1 Setting Forms 19
5.2 Checking Grades 19
5.3 Manual Grades 20
6 Batteries
21
6.1 Operating Principles 21
6.2 Battery for Zone20 H 21
7 Accuracy Adjustment
24
7.1 Checking the Level Accuracy 24
7.2 Adjusting the Level Accuracy 24
8 Troubleshooting
26
9 Care and Transport
28
9.1 Transport 28
9.2 Storage 28
9.3 Cleaning and Drying 28
10 Technical Data
29
10.1 Conformity to National Regulations 29
10.2 Dangerous Goods Regulations 29
10.3 General Technical Data of the Laser 29

GeoMax ZONE20 H Specifications

General

Brand	GeoMax
Model	ZONE20 H
Category	Measuring Instruments
Language	English
