G100 RANGE OPTIONAL PRODUCTS AND ACCESSORIES
Optional Products
The G100 analyser range has a number of optional products for purchase which enhance the usability
and enable further analysis of data and reading information.
Note: For more information on the features listed in this section please contact Sales at QED on
+44(0)330 800 0088 or email sales@qedenv.co.uk.
Analyser Data Manager (Optional)
Analyser Data Manager enables the user to maximise the operation of the incubator analyser.
Instrument readings and event log data may be downloaded to a PC for further analysis and exported
to other applications such as MS Excel. It enables direct communication with the unit, features a
simple download facility and is fully compatible with the latest Microsoft operating systems.
Event Log
The G100 instruments incorporate the facility to log significant events via the ‘Event Log’. This can be
used as an aid to monitoring the use of the instrument. It can also be used as a diagnostic tool if there
is a problem with the instrument.
The event log can only be viewed via the optional Analyser Data Manager software. It cannot be
viewed on the analyser screen. Applicable events are stored in the event log automatically. No user
intervention is required.
The event log can hold approximately 270 events. If the log becomes full then it begins to over-write
the older events. This can be identified by the index field which starts from event number 1. The log
is cleared when the instrument is reset.
Note: Please refer to section Event Log of this operating manual for further information.
Temperature Probe Reading (Optional)
The G100 range of instruments has the facility to read and display two temperature readings via
optional temperature probes. When a temperature probe is fitted to one of the two temperature
ports on the top of the instrument, the display will automatically show the current reading and a
temperature probe icon will be displayed.
The display can also be changed to show a T
1
– T
2
calculation by pressing the appropriate soft-key.
The current mode of operation can be identified by normal or inverse status of the soft-key, where
inverse indicates that the option is active.
Note: The T
1
– T
2
result is not stored as part of the reading.
The operator can also choose to display the reading in either Centigrade or Fahrenheit using the
temperature option accessed from the ‘Settings’ menu.
Humidity Probe Reading (Optional)
The instrument has the optional facility to use a humidity probe (specified at the time of
manufacture). This allows the instrument to read and display humidity readings from an optional
probe.
When a humidity probe is fitted, the display will change automatically to show the current reading
and a humidity probe icon will be displayed. The ‘Scroll’ keys on the instrument panel are used to
