October 29, 2015
3
1.2 GV-AS110 / 1110
2.3 Programming Mode
2.2.5 Connecting the Power
2.2.3 Connecting Output Devices
2.2.2 Connecting Input Devices
2.2.1 Connecting Card Readers
Connect card readers (Optional)
Connect AS110 / 1110 to a reader..
Connect input devices
Connect AS110 / 1110 to input devices (Ex: a push
button to exit).
Connect output devices
Connect AS110 / 1110 to output devices (Ex: a door
lock).
Connect to Power
Connect AS110 / 1110 to power using the supplied
adaptor.
Programming the GV-AS110 / 1110
Create an Enroll Card and a Delete Card to add and
delete cards. For other settings, use the built-in keypad
to type the commands.
GV-AS110 / 1110
2.2.4 Connecting the PC
Connect to PC
Connect the controller to a computer through RS485
connection (AS110) or network connection (AS110 &
AS1110).
To Next Page
