Administrator Mode
115
4 4
To enable the Center V2 connection:
1. Activate Link: Enable the monitoring through Center V2.
2. Host Name or IP Address: Type the host name or IP address of
Center V2.
3. Port Number: match the port to the Port 2 value on Center V2 or
keep the default value 5551.
4. User Name: type a valid username to log into Center V2.
5. Password: Type a valid password to log into Center V2
6. Click Apply. The Connection Status should display “Connected” and
connected time.
7. To establish connection to the second Center V2 server, click the
Connection 2 tab and repeat the above steps for setup.
You can also find the following options on this Center V2 setting page:
Cease motion detection messages from: Stops notifying Center V2
of motion-triggered events.
Cease input trigger messages from: Note this function is only
supported by cameras with I/O function. Stops notifying Center V2 of
input-triggered events.
Enable schedule mode: Starts the monitoring through Center V2
based on the schedule you set in the Select Schedule Time section.
Refer to 4.6 Recording Schedule for the same settings.
For related settings to activate the monitoring through Center V2, see 4.1.2
Motion Detection, 4.3.1 Input Setting and 8.1 Center V2.
