Administrator Mode
77
4 4
Figure 4-8
To configure the tampering alarm:
1. Select the Enable option.
2. If you want the camera to ignore any movement or scene change in
certain areas, click the
button to drag areas on the camera view.
3. Select the desired detection sensitivity by moving the slider. The
higher the value, the more sensitive the camera is to scene changes.
4. In the Tolerance Time of Alarm field, specify the time length allowed
for scene changes before an alarm is generated.
5. In the Duration of Alarm field, specify the duration of the alarm after
which the triggered output device will be turned off.
