GeoVision GV-NVR System Lite V2 User Manual

viii
Section B Single Stream Resolution (H.264)
Max.
Frame
Rate
Total
Frame
Rate
GV-FE110 / 111 1280 x 1024 (4:3) 7 fps 21 fps
GV-FE420 / 421 2048 x 1944 (4:3) 6 fps 6 fps
GV Fisheye
GV-FE520 / 521 /
GV-FER521
2560 x 1920 (4:3) 6 fps 6 fps
Section C Single Stream Resolution (H.264)
Max.
Frame
Rate
Total
Frame
Rate
640 x 480 30 fps 240 fps
Third-Party Camera
1280 x 720 15 fps 90 fps
Note:
GV IP cameras
1. For GV IP cameras (excluding GV Fisheye), stream 1 is used for recording and single view,
and stream 2 for live viewing in multi divisions.
2. The default resolution for stream 1 is set at its maximum. Several resolution, aspect ratio and
codec options are available for each IP camera, except GV-Fisheye cameras.
3. It is highly recommended to set the panel resolution to 1280 x 1024 (default) or lower when
connecting to GV Fisheye to get better CPU performance.
Third-party cameras
4. For third-party cameras, be sure the resolution and codec are configured as specified above
to achieve the best performance and maximum frame rate. To find the supported third-party
cameras, go to http://www.geovision.com.tw/english/4_21.asp
.
Frame Rate
5. Total Frame Rate equals to the Max. Frame Rate multiplies the supported channel numbers.
6. If you record the images, access live view and see the playback simultaneously, the CPU
loading will increase massively. Therefore, the frame rates may drop.
GV-NVR System Lite V2 Dongle
A dongle is required when connecting to third-party IP cameras.
Dongle Options: 1, 2, 4, 6 or 8 IP channels.
