1. Overview (See images 1 - 4)
2. FireFox
®
2 blind rivet nut setting tool
The blind rivet nut tool is designed exclusively for setting blind rivet nuts and blind rivet nut
studs as described in the operating instructions.
Please comply with all safety instructions!
2.1 Correct use
Item Designation Abb.
1 Locknut 1;3;4
2 Nosepiece 1;3;4
3 Threaded mandrel 1;3;4
4 Stroke adjuster 1
5 Stroke scale 1
6 Release button 1
7 Wind down button 1
8 Allen key 1
9 Adjustable screw with colour
scale
2
10 Display window 2
11 Slide 3
12 Oilrellscrew 1
13 Seal 1
2.2 Safety instructions
• The blind rivet nut setting tool should only be used for setting blind rivet nuts and blind rivet
nut studs.
• Improperusewhenwindingdownandsettingnutsposesariskofcrushingyourngers!
• Do not overload the blind rivet nut setting tool; work within the prescribed work capacity.
• Do not exceed the permitted operating pressure.
• Do not rivet outside of riveting holes!
• Checkconnectinglinesforcompressedairatregularintervalsforforcetandtightness.
