Gesipa FireFox 2 - Work Capacity; Technical Data; Equipment and Accessories

19
GB
Weight: 2.4 kg
Working pressure: 5 to 7 bar
Gun stroke: max. 10 mm
Hose connection: Ø 6 mm (1/4“)
Compressed air consumption: c. 2 - 4 litre/setting process (dependent on nut size)
Setting force at 5 bar: 18.5 kN
Hydraulic oil: ca. 30 ml (ISO VG 32 to 46)
Noise emission Lpa: 75 dB, Measurement uncertainty K=3dB
Vibration: < 2.5 m/s², Measurement uncertainty K=1.5 m/s²
Compressed air quality: Filtered
2.4 Technical data
• Disconnect the device from the compressed air network prior to carrying out any
maintenance work to the blind rivet nut setting tool, changing threaded mandrels or when
not in use.
• When working with the tool, always wear protective goggles. Personal protection like clothes,
gloves, safety helmet, ear protection and anti-fall protection are highly recommended.
• When depositing the blind rivet setting tool, make sure that it cannot fall.
• Repair work must be carried out by skilled personnel. Use genuine parts for repair at all
times. In case of doubt, always send the complete blind rivet nut setting tool back to the
supplier or to GESIPA
®
.
• Avoid excessive contact with hydraulic oil. If irritation of the skin occurs, wash affected skin
parts thoroughly with water!
• Dispose of hydraulic waste oil according to current regulations.
2.3 Work capacity
The blind rivet nut setting tool is designed for setting blind rivet nuts and blind rivet bolts M3 to
M10 made of any kind of material, as well as M12 in aluminium and steel.
Threaded mandrels M4, M5, M6 and M8
and nosepiece:
Tool: Hexagon screw driver SW3
2 x double open-end spanner SW24/27
Suspension Loop: Extendable from device top
Hydraulic oil: 1 bottle of hydraulic oil 100 ml
   1oilllingcontainer
2.5 Equipment/accessories
