1. Use in accordance with the operating instructions
The tool should be used only in accordance with these operating instructions for setting blind
rivet nuts.
The safety instructions must be followed!
2. Safety instructions
• The tool is to be used only for setting blind rivet nuts.
• Do not overload the tool. Work only within the indicated capability range.
• Do not operate the tool without installing a rivet nut.
• Regularly check compressed air connections with respect to tightness and leakage.
• Always disconnect the tool from compressed air supply when tool is not in use or when
servicing.
• When working with the tool, always wear protective safety glasses. Personal safety
equipment such as protective clothing, protective gloves, helmet, nonslip shoes and hea-
ring protection are recommended in order to safeguard against accidents.
• Keep long hair or loose clothing away from the tool during operation or when servicing.
• Repairs should be carried out by trained personnel only. If in doubt, return the tool to the
supplier.
• Used hydraulic oil must be disposed of in accordance with environmental regulations.
3. Working range
4. Technical data
Blind rivet nuts from M3 to M10, all materials.
Weight: 2.3 kg
Operating air pressure: 6 bar
Air connection: 6 mm Ø (1/4´´)
Air consumption: approx. 8 NI per cycle
Compressedairquality:  lteredanddryed
Traction power: 15,700 N (1,600 kp)
Hydraulic oil: approx. 30 ml ISO VG 46
Noise emission: L
pa
82.5 dB, Measurement uncertainty K=3dB
Vibration: <2.5 m/s², Measurement uncertainty K=1.5 m/s²
