54
Using PC Cards (Select Models Only)
Select Expansion models have a PC Card slot. The PC Card slot supports type II
card and CardBus specifications.
To insert a PC Card:
1. Locate the PC Card slot and open the protective cover.
2. Slide the PC Card, with its label facing up, into the slot until the eject
button pops out.
3. Close the cover.
To remove a PC Card:
1. Open the cover.
2. Double-click the Safely Remove Hardware icon found on the Windows
taskbar and the Safely Remove Hardware window appears on screen.
3. Select (highlight) the PC Card from the list to disable the card.
4. Push the eject button and the card will slide out slightly.
5. Pull the card out of the slot.
6. Close the cover.
