Component Description
Light sensor
Detects the surrounding lighting condition for
automatic adjustment of the LCD brightness.
P1 button Opens or closes the OSD Control Panel.
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.
P2 button
The default function is Camera or Barcode Trigger
depending on your model.
Camera
Starts the G-Camera application.
B
Trigger
Serves as the trigger button for the barcode
scanner if your model has the module.
Windows logo
button
Opens or closes the Start menu.
Plus button Increases the sound volume.
Minus button Decreases the sound volume.
Power button
Turns the power on or off. (The default “off” state
is “Sleep mode.”)
Speaker Sends out sound and voice from your Tablet PC.
Microphone Receives sound and voice to record voice.
Indicators
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
Battery Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this
period.
Blinks red (once per second) when the battery’s
capacity is below 10%.
