3
Installing the Micro-SIM Card (Optional)
NOTE: The micro-SIM card socket is located below the battery pack. If you
have already installed the battery pack, remove it in order to install the
micro-SIM card.
CAUTION: Before installing the micro-SIM card, make sure the AC adapter is
not connected and the power is not turned on.
1. Locate the micro-SIM card socket. Remove one screw to detach the small
metal plate that covers the micro-SIM card socket.
2. Slide the socket cover toward the unlocked direction ( ) and open
the cover.
3. Noting the orientation, put down the micro-SIM card on the socket.
4. Close the cover and slide it back to the locked position ( ).
5. Replace the metal plate and secure it in place with the screw previously
removed.
