Appendix A
Specifications
NOTE: Specifications are subject to change without any prior notice.
Parts Specifications
CPU Alder Lake U Platform
- Intel® Pentium™ 8505, up to 4.4GHz, 8M cache
- Intel® Core™ i5-1235U, up to 4.4GHz, 12M cache
- Intel® Core™ i5-1245U, up to 4.4GHz, 12M cache
- Intel® Core™ i7-1255U, up to 4.7GHz, 12M cache
- Intel® Core™ i7-1265U, up to 4.8GHz, 12M cache
BIOS Insyde, Flash EEPROM, 32MB, UEFI, supporting ACPI, TPM,
Computrace, AMT12, WMI, and BIOS diagnostic
RAM 8/16/32GB DDR4, 3200MHz
Video Controller Intel® UHD Graphics
Display
Panel
10.1-inch (16:9) TFT LCD, FHD 1920 x 1200, dimmer mode,
blackout mode, sunlight readable, 1000 nits standard
brightness
Touchscreen Capacitive multi-touch screen - 10 points
Audio Features High Definition audio
Speaker 1.5 W
Microphone
Integrated x 2, Mic Array
Mass storage device 256GB/512GB/1TB SSD (Solid-State Drive), M.2 2280 Form
Factor, PCIe interface
I/O ports USB 3.2 Gen 2, USB-C Thunderbolt 4, combo audio (4-pole
TRRS 3.5mm type), RJ45 (option), Docking, tri antenna
passthrough (option)
Mutually-exclusive
I/O
One of the below on the top side:
Barcode scanner / HDMI / HF RFID reader / microSD card / RS-
232 serial / USB 3.2 Gen 1 / RJ45
Card readers Smart Card (option)
HF RFID (option)
MicroSD card (option)
