15
Ref
Component Description
e
RS-232 serial
connector
Connects a serial device.
f RJ45 connector Connects the LAN cable.
g
USB 3.2 Gen 1
port
Connects a USB device.
Bottom Components
Ref
Component Description
Docking
connector
Connects a proprietary dock such as the keyboard
dock, office dock, and vehicle dock.
Tri antenna
passthrough
(optional)
Connects to the docking station for using external
GPS/WWAN/WLAN antenna.
