SERVICE MANUAL ProSeal Classic/Plus/Premium
12
strip around the heating cables. Do not touch the cleaned bonding surface and
press the strip thoroughly over the complete area.
 Cut a notch into the PTFE strip (1) (Pic 15).
Pic 15
 See paragraph 4.3.1 for the mounting instruction of the heating elements to
the base frame.
2.4 Transport belts
During use, the transport belts in the ProSeal will start to get worn out. It is therefore
important to replace the transport belt during preventive maintenance.
 Remove the belt guides (paragraph 2.3.1). It is not necessary to remove the
heating elements.
 Remove the clamp with a circlip plier holding the smooth wheel in place
(Pic 16). Do this with the upper and lower wheel.
Pic 16
 Remove the upper and lower smooth wheel (Pic 17) and replace the transport
belt. Make sure that the arrows on the belt are pointing in the movement
direction of the belt.
Pic 17
1
1
1
