43
• Fixing the WallBox to the wall (not valid for codes GWJ3001A, GWJ3002A, GWJ3003A, GWJ3004A,
GWJ3011A, GWJ3012A, GWJ3013A, GWJ3014A)
Eliminate the relevant knockouts on the basis of the cable inlet chosen (A from below, B from the rear), then fix
the box in the wall
B
A
Insert the WallBox in the box
