Ghost Controls Ghost Pro Series - Mounting Front Mount and Estate Bracket; Step 14: Align and Mark Gate Bracket Holes; Gate Position for Mounting

32
PULLTOOPEN
©Ghost Controls
®
2020
STEP 14. Mounting the FRONT MOUNT AND ESTATE BRACKET to the gate.
OPEN THE GATE TO THE DESIRED OPEN POSITION
(this will be the position that your gate will always open to)
A. Line up the pre-assembled front mount gate bracket over the center-most bar on your gate and mark the
center location of the outermost hole on the gate.
WARNING
DO NOT SCREW THE OPERATOR ARM IN OR OUT TO ADJUST YOUR GATE POSITION. DOING SO
CAUSES THE SYSTEM TO NOT FUNCTION PROPERLY.
CL
Drill hole
