Gigabyte GA-F2A85X-UP4 User Manual

- 11 -
Hardware Installation
Storage Interface  Chipset:
- 7xSATA6Gb/sconnectors(SATA30~6)supportingupto7SATA6Gb/s
devices
- 1 x eSATA 6Gb/s connector on the back panel supporting up to 1 SATA 6Gb/s
device
* Actualtransferrateisdependentonthedevicebeingconnected.
- Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
USB  Chipset:
- Upto4USB3.0/2.0ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
- Upto10USB2.0/1.1ports(2portsonthebackpanel,8portsavailable
throughtheinternalUSBheaders)
 Etron EJ168 chip:
- Up to 2 USB 3.0/2.0 ports on the back panel
* BesuretoconnectyourUSBdevice(s)totheUSB2.0/1.1portsbeforetheUSB3.0
driverisinstalled.(Refertothelabelsinsection1-8,"BackPanelConnectors.")
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 7 x SATA 6Gb/s connectors
 1 x APU fan header
 4 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x USB 3.0/2.0 header
 4 x USB 2.0/1.1 headers
 1 x serial port header
 1 x Clear CMOS jumper
 1xTrustedPlatformModule(TPM)header
 1 x power button
 1 x reset button
 1 x Clear CMOS button
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x D-Sub port
 1 x DVI-D port
 1 x optical S/PDIF Out connector
 1 x HDMI port
 1 x DisplayPort
 4 x USB 3.0/2.0 ports
 2 x USB 2.0/1.1 ports
 1 x eSATA 6Gb/s connector
 1 x RJ-45 port
 6xaudiojacks(Center/SubwooferSpeakerOut/RearSpeakerOut/SideSpeaker
Out/LineIn/LineOut/Microphone)

Gigabyte GA-F2A85X-UP4 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	-
Processor manufacturer	AMD
Compatible processor series	AMD Athlon
Power fan connector	Yes
Number of SATA III connectors	7
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	2
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	AMD A85X
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA III
PCI Express x1 slots	3
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI

Weight and Dimensions

Depth	244 mm
Width	305 mm
