Hardware Installation
- 24 -
1-9 Internal Connectors
Read the following guidelines before connecting external devices:
First make sure your devices are compliant with the connectors you wish to connect.
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) BAT
6) SATA3 0/1/2/3/4/5/6
7) CLR_CMOS
8) F_PANEL
9) F_AUDIO
10) SPDIF_O
11) F_USB30
12) F_USB1/F_USB2/F_USB3/F_USB4
13) COM
14) TPM
15) PW_SW
16) RST_SW
17) CMOS_SW
12
5
3
10
1 174
2
4
15
16
7
6
6
14139
4
11
84
