Gigabyte GA-F2A85X-UP4 User Manual

Hardware Installation
- 10 -
1-2 ProductSpecications
APU  FM2 Socket:
- AMD A series processors
- AMD Athlon
™
series processors
(Go to GIGABYTE's website for the latest APU support list.)
Chipset  AMD A85X
Memory  4 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of
physical memory is installed, the actual memory size displayed will be less than the
size of the physical memory installed.
 Dual channel memory architecture
 Support for DDR3 1866/1600/1333/1066 MHz memory modules
 Support for AMD Memory Prole (AMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 APU:
* To use the onboard graphics ports, you must install an AMD APU with integrated
graphics.
- 1 x D-Sub port
- 1 x DVI-D port, supporting a maximum resolution of 2560x1600
* Support for 2560x1600 resolution requires both a monitor and cable that support
Dual Link DVI.
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
- 1 x DisplayPort, supporting a maximum resolution of 2560x1600
(The DisplayPort port does not support Hot plug. If you want to change to another
graphics port when the computer is on, be sure to turn off the computer rst.)
Audio  Realtek ALC892 codec
 High Denition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot will operate at up to x8 mode.
 1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX1_3 slot shares bandwidth with the PCIEX4 slot. When the PCIEX1_3 slot
is populated, the PCIEX4 slot will operate at up to x1 mode.
 3 x PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 standard.)
 1 x PCI slot
Multi-Graphics
Technology
 Support for AMD CrossFire
™
technology (The PCIEX16 and PCIEX8 slots only.)
 Support for AMD Dual Graphics technology
* Only A series APUs support AMD Dual Graphics.

Gigabyte GA-F2A85X-UP4 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	-
Processor manufacturer	AMD
Compatible processor series	AMD Athlon
Power fan connector	Yes
Number of SATA III connectors	7
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	2
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC892
Component for	PC
Motherboard chipset	AMD A85X
Audio output channels	7.1 channels
Motherboard form factor	ATX
Supported storage drive interfaces	SATA III
PCI Express x1 slots	3
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI

Weight and Dimensions

Depth	244 mm
Width	305 mm
