Gigabyte GA-Z87X-OC User Manual

- 10 -
Hardware Installation
1-2 ProductSpecications
CPU

Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors in the LGA1150 package
(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU
Chipset

Intel
®
Z87 Express Chipset
Memory

4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of
physical memory is installed, the actual memory size displayed will be less than
the size of the physical memory installed.

Dual channel memory architecture

Support for DDR3 1600/1333 MHz memory modules

Support for non-ECC memory modules

Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 2 x HDMI ports, supporting a maximum resolution of 4096x2160
* Support for HDMI 1.4a version.
- 1 x DisplayPort port, supporting a maximum resolution of 3840x2160
* Support for DisplayPort 1.2 version.
- Maximum shared memory of 1 GB
Audio

Realtek
®
ALC892 codec

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF In

Support for S/PDIF Out
LAN

Intel
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one expansion card is to be installed, be sure to
install it in the PCIEX16 slot.
 1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. It will operate at up to x8
mode when the PCIEX16 is populated.
 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2)
* The PCIEX4_1 slot shares bandwidth with the PCIEX16 and PCIEX8 slots. When
it is populated, the PCIEX16 slot will operate at up to x8 mode and the PCIEX8 slot
will operate at up to x4 mode.
* When installing a x8 or above card in the PCIEX4_1 slot, make sure to set PCIE Slot
Conguration in BIOS Setup to x4. (Refer to Chapter 2, "BIOS Setup," "Peripherals,"
for more information.)
(The PCIEX16, PCIEX8, and PCIEX4_1 slots conform to PCI Express 3.0
standard.)
 1 x PCI Express x1 slot
(The PCIEX4_2 and PCIEX1_1 slots conform to PCI Express 2.0 standard.)
 2 x PCI slots

Gigabyte GA-Z87X-OC Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 3000 MHz
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Supported processor sockets	LGA 1150 (Socket H3)
Maximum number of SMP processors	1
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® Z87
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 4-Way CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x8, 1x16, 2x4
Cables included	SATA
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
