6-1-3 ConguringMicrophoneRecording
Step 1:
After installing the audio driver, the HDAudioManager
icon will appear in the notication area. Double-click
the icon to access the HDAudioManager.
Step 2:
Connect your microphone to the Mic in jack (pink) on the
back panel or the Mic in jack (pink) on the front panel.
Then congure the jack for microphone functionality.
Note: The microphone functions on the front panel and
back panel cannot be used at the same time.
Step 3:
Go to the Microphone screen. Do not mute the recording
volume, or you'll not be able to record the sound. To hear
the sound being recorded during the recording process,
do not mute the playback volume. It is recommended that
you set the volumes at a middle level.
Step 4:
To raise the recording and playback volume for the
microphone, click the MicrophoneBoost icon on
the right of the RecordingVolume slider and set the
Microphone Boost level.
