- 86 -
5-2-1 EasyTune
GIGABYTE's EasyTune is a simple and easy-to-use interface that allows users to ne-tune their system settings
or do overclock/overvoltage in Windows environment. The user-friendly EasyTune interface also includes tabbed
pages for CPU and memory information, letting users read their system-related information without the need
to install additional software.
The EasyTune Interface
Tabs Information
Tab Function
The System Information tab provides information on the installed CPU and motherboard.
Smart Quick Boost provides you with different levels of CPU frequency to choose to achieve
desired system performance. After making changes, be sure to restart your system for these
changes to take effect. The Advanced menu allows you to change specic clock/frequency/
votlage settings.
The Smart Fan tab allows you to specify a Smart Fan mode. The Calibrate menu displays
the detected linear fan speed for the fans on the motherboard from the fastest to the slowest.
The Advanced menu allows you to set temperature thresholds, based on which the fan speed
can be changed linearly.
The System Alerts tab allows you to monitor hardware temperature, voltage and fan speed
and set temperature/fan speed alarm.
The 3D Power tab allows you to change power phase and voltage settings.
Incorrectly doing overclock/overvoltage may result in damage to the hardware components such
as CPU, chipset, and memory and reduce the useful life of these components. Before you do the
overclock/overvoltage, make sure that you fully know each function of EasyTune, or system instability
or other unexpected results may occur.
Available functions in EasyTune may differ by motherboard model. Grayed-out area(s) indicates that
the item is not congurable or the function is not supported.
