- 8 -
GA-Z87X-OC Motherboard Block Diagram
Fordetailedproductinformation/limitation(s),referto"1-2ProductSpecications."
LGA1150
CPU
CPUCLK+/-(100MHz)
Dual BIOS
8 USB 2.0/1.1
DDR31600/1333MHz
Dual Channel Memory
DMI 2.0
FDI
6 SATA 6Gb/s
2 USB 3.0/2.0
LPC Bus
PCIe CLK
(100MHz)
PCI Express Bus
1 PCI Express x8
2 PCI Express x4
x8
x8
Switch
1 PCI Express x16
x16
Switch
2 PCI Express x8
x16
PS/2 KB/Mouse
iTE
®
Super I/O
HDMI
HDMI
DisplayPort
Intel
®
Z87
COM
4 USB 3.0/2.0
Renesas
®
uPD720210 Hub
4 USB 3.0/2.0
Renesas
®
uPD720210 Hub
PCI Express Bus
PCIe CLK
(100MHz)
1 PCI Express x1
x1
LAN
RJ45
Intel
®
GbE
LAN
Center/Subwoofer Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Rear Speaker Out
S/PDIF In
x1
Side Speaker Out
CODEC
x4
1 PCI Express x4
2 PCI
PCI Bus
PCI CLK
(33MHz)
PCIe to PCI
Bridge
x1
