Gigabyte MZ73-LM1 User Manual

- 12 -
Hardware Installation
Socket
Socket
Security
Security Server
Operating Properties
Power SupplySystem fan
Expansion Slots MZ73-LM0
 Slot_4: 1 x PCIe x16 (Gen5 x16 bus) slot. from CPU_0
 Slot_3: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_0
 Slot_2: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_1
 Slot_1: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU_1
 1 x M.2 slots:
- M-key
- PCIe Gen4 x4 from CPU_0
- Supports 2280/22110 cards
 2x MCIO 8i with 4 x Gen5 NVMe or 16 x SATA ports, from CPU_1
MZ73-LM1
 Slot_4: 1 x PCIe x16 (Gen4 x16 bus) slot. from CPU_0
 Slot_3: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_0
 Slot_2: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
 Slot_1: 1 x PCIe x16 (Gen4 x16 bus) slot, from CPU_1
 1 x M.2 slots:
- M-key
- PCIe Gen4 x4 from CPU_0
- Supports 2280/22110 cards
 2 x SlimSAS 8i with 4 x Gen4 NVMe or 16 x SATA ports from CPU_1
Socket
Socket
Security
Security Server
Operating Properties
Power SupplySystem fan
Internal I/O
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connectors
 2 x 6-pin ATX 12V power connectors
 2 x SlimSAS 8i connectors
 1 x M.2 slot
 2 x CPU fan headers
 3 x System fan headers
 1 x USB 3.2 Gen1 header
 1 x TPM header
 1 x Front panel header
 1 x HDD back plane board header
 1 x PMBus connector
 1 x IPMB connector
 1xClearCMOSjumper
 1xBIOSrecoveryjumper
 1 x Buzzer
Socket
Socket
Security
Security Server
Operating Properties
Power SupplySystem fan
Rear I/O
Connectors
 2 x USB 3.2 Gen1
 1 x VGA
 1 x COM
 2 x RJ45
 1 x MLAN
 1 x ID button with LED

Gigabyte MZ73-LM1 Specifications

General

Brand	Gigabyte
Model	MZ73-LM1
Category	Motherboard
Language	English
