Hardware Installation

20) CASE_OPEN (Case Open Intrusion Alert Header)

This motherboard provides a chassis detection feature that detects if the chassis cover has been removed.

This function requires a chassis with chassis intrusion detection design.

Open: Normal Operation (Default)

Closed: Active Chassis Intrusion Alert
