- Insert the following from the top of the stem:
1 Bushing "B"
2 Abutment washer "C"
3 Oil guard "D"
- Insert the pumping member guiding bushing at
the bottom end of the stem.
- Insert the stem into the casing being careful not to let the guiding bushing come out of the stem.
- Move the oil guard in abutment using a tube.
TUBE SIZE
Specification
Desc./Quantity
Inside: 44 mm
Outside: 51 mm
Height: approx. 105 mm
Nexus 500 euro 3 Suspensions
SUSP - 297
