Taillight assy.
- Remove the side fairings.
- Remove the upper central screw.
- Using a wrench offset by 10 mm between the under-saddle compartment and the tubes of the frame,
loosen the 2 rear retaining bolts and then disconnect the retainers of the lights at the ends of the support.
- Remove the light and disconnect the bulb holder by turning it through 30° in anticlockwise direction.
Footrest
- Remove the centre union.
- Remove the side fairings.
- Remove the mat of the footrest.
- Remove the screws indicated in the figure.
Chassis Nexus 500 euro 3
CHAS - 346
