- From the underside it is possible to loosen the 3
retaining screws and to release the 2 locking tabs
to raise the mounting plate of the steering lock
strut.
- The latter has a retaining tab with cylindrical teeth
that cannot be replaced.
Front wheel housing
- Remove the spoiler.
- Remove the front fork.
- Remove the plate supporting bracket for the horn
and voltage regulator by loosening the two retain-
ing screws shown in the figure in order to release
the two lower retainer of the wheel housing.
- Remove the upper fixing screw of the wheel
housing to permit movement.
- In order to remove the wheel housing it is necessary to remove the front brake hose to the tank and
combination with the splitter.
Nexus 500 euro 3 Chassis
CHAS - 345
