10. Left turn indicator
11. Fixed battery
12. Immobilizer LED
13. Permanent power supply (+)
14. Turn indicator assembly
15. Pump level sensor
16. -
17. Injection LED
18. Right turn indicator warning light
19. Left turn indicator warning light
20. Emergency warning flashers
Connector "B"
KEY:
1. Rpm indicator (D)
2. Rpm indicator (B)
3. -
4. -
5. ICP/ID "NEXUS 500"
6. ICP/ID "NEXUS 250"
7. Rpm indicator (C)
8. Rpm indicator (A)
9. -
10. -
11. -
12. ICP/ID "COMAND ID"
Analogue odometer
ANALOGUE RPM INDICATOR
Specification Desc./Quantity
1 STEPPER MOTOR A
2 STEPPER MOTOR B
3 STEPPER MOTOR C
4 STEPPER MOTOR D
Remote seat opening
The vehicle is equipped with a remote control to open the saddle.
Nexus 500 euro 3 Electrical system
ELE SYS - 75
