Vehicle identification

VEHICLE IDENTIFICATION

Specification Desc./Quantity

Frame prefix ZAPC2700000001001

Engine prefix C271M

Dimensions and mass

DIMENSIONS AND MASS

Specification

Desc./Quantity

Maximum width 780 mm

Maximum length 1970 mm

Wheel base 1350 mm

Saddle height 810 mm

Dry weight 99 kg.

Characteristics DNA 50

CHAR - 8
