020335Y Magnetic support for dial gauge
Characteristic
Axial clearance with warm crankcase
0.10 ÷ 0.12 mm
Axial clearance with cold crankcase
0.06 to 0.08 mm
Limit value with cold crankcase
0.02 ÷ 0.03 mm
Lubrication
Crankshaft oil seals
Refitting
- Install a new flywheel-side oil seal only with the
special tool's punch
The flywheel-side oil seal is recognised by its
smaller diameter
N.B.
THE USE OF THE SPECIFIC TOOL IS NOT
COMPATIBLE WITH THE FITTED WRENCH
Specific tooling
020340Y Flywheel and transmission oil seals
fitting punch
- Install a new transmission side oil seal using the
special tool with adapter ring.
The transmission-side oil seal is recognised by the
larger diameter
Specific tooling
020340Y Flywheel and transmission oil seals
fitting punch
Oil pump
DNA 50 Engine
ENG - 89
