Issue: 8 (Applies to firmware 2387 6.09 onwards)
Document number: 1390-PS-0039
Ultrasonic Anemometer
Ox – ASCII Output Format (Output String Padding)
Setting
Configuration code
Comma Separated Variable (CSV)
O1
Fixed Field
O2
Example data strings: -
POLAR
NMEA
CSV
data changing to error status code condition.
CSV
data changing to error status code condition
.
A,235,000.77,M,00,0A
$IIMWV,191,R,000.55,M,A*19
A,,,M,04,24
$IIMWV,,R,,M,V*29
Fixed Field data changing to error status code
condition.
Fixed Field data changing to error status code
condition.
A,266,000.73,M,00,08
$IIMWV,191,R,000.55,M,A*19
A,999,999.99,M,04,0A
$IIMWV,999,R,999.99,M,V*07
Px - Output Rate
Outputs per second
1
2 4 5 8 10
Configuration code
P1
P3 P2 P4 P5 P6
Q- Measurement Mode
See page 51
RWASHORT XX (Short term number)
Where XX = 10 to 60, associated with Mode 14 and Mode 15 averaging.
RWALONG XX (Long term number)
Where XX = 1 to 10, associated with Mode 14 and Mode 15 averaging.
Tx - Analogue Output Voltage or Current settings (N/A)
