ASPEC® POSITIVE PRESSURE MANIFOLD | USER'S GUIDE
INTRODUCTION
Pressure Gauge
Monitors the operating pressure of the system, which should not exceed
15psi.
SPE Cartridge Plugs (Optional)
Used to fill empty positions in the SPE cartridge racks (15- and 24-position).
Figure 11
Pressure Gauge
Plugs
Rear Rows
Empty
Position
SPE Cartridges
(Front Row)
Figure 12
Plugs on 24-Position Rack
