Gima CONTEC 8000 - Chapter 8 New Patient Sampling; 8.1 New Patient Data Input

3
1
E(C2)
Light blue/Yellow
E(V2)
Orange/Yellow
C(C3)
Light blue/Green
C(V3)
Orange/Green
A(C4)
Light blue/Brown
A(V4)
Orange/Brown
M(C5)
Light blue/Black
M(V5)
Orange/Black
H(C6)
Light blue/Violet
H(V6)
Orange/Violet
The electrode placement positions of Wilson Lead System are shown as Figure 16.
F
igure 16
