17
Figure 4-3-1-3 The entire wearing of sensor
Note:
 Wear the Nasal cannula according to the regulations, or it will affect the gath-
ering effect.
4.3.2 SpO2 and Pulse Rate Monitoring
The scheme of the following three probe could be chose by user, as table 4-3-2.
Table 4-3-2
Figure 4-3-2-1 One-off adhesive SpO2 probe Figure 4-3-2-2 Adult ngertip SpO2 probe
ENGLISH
Appellation Quantity Scheme
One-off adhesive SpO2 probe 2 Standard (Figure 4-3-2-1)
Adult ngertip SpO2 probe 1 Standard (Figure 4-3-2-2)
Binding SpO2 probe 1 Optional (Figure 4-3-2-3)

