Edit mode 22
Code no. 576017
Rev. nº 02/0415
Programming the drying temperature
Maximum temperature of the air in the heating
area. In the example, set at 200 ºC.
Increasing the programmed temperature
Max. temp. that can be programmed: 200 ºC
(392 ºF).
Decreasing the programmed temperature.
Minimum temperature programmable: 40 ºC
(104 ºF).
Confirming the selection of the programmed
temperature.
Accessing the following screen.
Back to the previous menu.
Rotation speed
The rotation speed is maintained in the drying and
cooling-down stages.
Selecting the speed option (see options
tables: Section 7.1.4).
Confirming the programmed option.
Accessing the following screen.
Back to the previous menu.
Rotation
The rotation intervals are maintained in the drying
and cooling-down stages.
Selecting the start and stop times (see
options tables: Section 7.1.4).
Confirming the programmed option.
Accessing the following screen.
Back to the previous menu.
