LOGI CONTROL. Advanced mode 36
Cod. 523340
Rev. 10/1016
Temperature of the bath
This allows the user to modify the water temperature in the phases in which this function is available. In other
phases, it is not possible to program the water temperature.
OPTIONS
MEANING
C-00 ... C-90
F 32 ... F 194
Programmable range in soak, pre-wash and wash phases
C-**: degrees Celsius
F***: degrees Fahrenheit
C-00 ... C-60
F 32 ... F 140
Programmable range in the pre-wash and last rinse phase
C-**: degrees Celsius
F***: degrees Fahrenheit
The ▲/▼ keys allow the user to modify the option displayed.
The key validates the selection on the display and allows the user to access the following programmable
function.
Dosings
This allows the dosing of each phase to be selected.
OPTIONS
MEANING
d-0
Without dosing
d-1
Dosing via pre-wash compartment
Pre-wash external dosing signal
Programmable in the soak and pre-wash phases (Ph 1…3)
d-2
Dosing via wash compartment
Wash external dosing signal
Programmable only in the wash phase (Ph 4)
d-3
Dosing via whitening compartment
Whitening external dosing signal
Programmable in the 1 to 4 rinse phases (Ph 5…8)
d-4
Dosing via softener or neutraliser compartment
Softener or neutraliser external dosing signal
Programmable only in the last rinse phase (Ph 9)
The external dosing signals are simultaneously activated with the water inlets through the dispenser.
The ▲ key allows the user to modify the option displayed.
The key validates the selection on the display and allows the user to access the following programmable
function.
Rotation sequence
The mechanical action of the washing machine with regard to the laundry is different according to the selected
ON/OFF sequence.
Time ON: drum rotating
Time OFF: drum stopped
OPTIONS
MEANING
r-1
Vigorous sequence rotation:
ON: 25 sec. OFF: 5 sec.
r-2
Normal rotation sequence
ON: 15 sec. OFF: 15 sec.
r-3
Light rotation sequence
ON: 5 sec. OFF: 25 sec.
The ▲key allows the user to modify the option displayed.
The key validates the selection on the display and allows the user to access the following programmable
function.
