GLOW T180 - Page 29

Glow T180
Tankless Condensing Water Heater
29
Domestic
water supply
Anti-scald
mixing valve
Hot Water Outlets
Glow T180 Water Heater with Airmax Fan Coil
Airmax Air Handler (c/w pump timer for potable water flush)
T
Conductors to suit stat choice
120/ 1 /60
Expansion tank required if
check valve used in domestic water supply
(as per local codes)
Air Vent at Highest
Point
PRV valve
Three Speed Pump
Glow T180 Water Heater
(Suitable for combination
water (potable) heating
and space heating and
not suitable for space heating only)
inlet
outlet
gas
120/ 1 /60
Figure 3.8
Pipe to drain
Ball Valve
Check Valve
Hose Bib
Must be
installed
Union
One size larger
diameter
