Glow T180
Tankless Condensing Water Heater
76
Parts List For Electrical Connections - Figure 8.8
Connector Harness # Description
J1 FM-180-HRN-006 POWER SUPPLY CABLE WITH PLUG (120V,60HZ)
J3 FM-180-HRN-002 SAFETY, FLUE AND WATER TEMPERATURE WIRING HARNESS
J4 FM-180-HRN-005 IGNITION TRANSFORMER AND IONIZATION ELECTRODE
HARNESS
J5,J12 FM-180-HRN-001 FAN, GAS VALVE WIRING HARNESS
J6 FM-180-HRN-004 FLOW SENSOR AND BLOCKED FLUE SWITCH HARNESS
J9 FM-180-HRN-007 DISPLAY BOARD WIRING HARNESS
GROUNDWIRE FM-180-HRN-003 IGNITION ELECTRODE GROUND WIRE
Part # Description
EKA-323-29 DHW HIGH TEMP LIMIT SWITCH
GLO-42 HEAT EXCHANGER FLUE TEMP SENSOR
GLO-41 DCW TEMP SENSOR
GLO-41 HEAT EXCHANGER OUTLET WATER TEMP SENSOR
GLO-41 DHW TEMP SENSOR
GLO-180-150 BLOCKED FLUE SWITCH (N/C)
GLO-52 DCW FLOW SENSOR
GLO-551 DISPLAY BOARD
GLO-552 IGNITION CONTROL BOARD (ICB)
GLO-553 ICB FUSE 3.15 AMP, 250V
GLO-541 NG, GAS VALVE
GLO-542 LPG, GAS VALVE
GLO-581 STAINLESS STEEL HEAT EXCHANGER WITH MICROFUSE (NOT REPLACABLE)
GLO-543 FAN
GLO-44 LEAD, IONIZATION ELECTRODE CABLE
GLO-583 IONIZATION ELECTRODE
GLO-43 LEAD, IGNITION ELECTRODE CABLE
GLO-582 IGNITION ELECTRODE
GLO-49 IGNITION TRANSFORMER
GLO-301 IGNITION TRANSFORMER MOUNTING BRACKET
Acronym
T_DCW DOMESTIC COLD WATER TEMP
T_HEX_OUT HEAT EXCHNAGER OUTLET WATER TEMP
T_DHW_OUT DOMESTIC HOT WATER TEMP
