SECTION VIID CANDI MODULE
2005 Tech 2 User’s Guide VII - 69
Connection of CANdi Module to Tech 2
The CANdi module connects to the Tech 2 by the existing Burndy data link connector (DLC). The vehicle
side connection remains unchanged using the existing adapter to interface between the DLC cable and
the SAE J-1962 adapter, as shown in Figure VIID-3.
Figure VIID-3
CANdi module connections
IMPORTANT
To ensure accurate test results, you must install Tech 2 software version 23.005 (August 2003) or later.
Tech 2 - VCI - Cable Test
Before using the CANdi module, perform the Tech 2 - VCI - cable test described in Appendix 1 to verify the
integrity of the system. Refer to Figure V-5 to see the connector end views of the DLC loopback adapter.
Necessary components are:
1. Tech 2 with VCI module installed
2. DLC Burndy cable
3. AC/DC power source
4. DLC loopback adapter (P/N 3000109), connected directly to the VCI module as shown in Figure VI-4
Appendix 1
Tech 2 - VCI - cable system test
