SECTION III GETTING STARTED
2005 Tech 2 User’s Guide III - 4
Vehicle Communications Interface Module Removal
The Vehicle Communications Interface (VCI) module is located at the lower end of the Tech 2. Removal of
this module is required only if the VCI needs to be updated or replaced.
To remove the module disconnect Tech 2 DLC cable if attached, move the lever (Figure III-11) all the way
toward the right side of the Tech 2 (Figure III-12). The VCI module can now be removed.
Figure III-12
VCI module removed
Figure III-11
VCI module removal
Hand Strap Adjustment
The Tech 2 velcro hand straps may be adjusted for individual needs as shown in the illustration below
(Figure III-13).
Figure III-13
Tech 2 hand strap adjustment
