TX6160 INSTRUCTION MANUAL
CONTROLS
This section provides gures and a table that describes various parts of the TX6160 radio.
TX6160 Instrucon Manual
14 June 2018
© 2018 Standard Communicaons Pty Ltd trading as GME. All rights reserved.
12
50158
Content
Controls
This secon provides gures and a table that describes various parts of the TX6160 radio.
3
4
5
1
7
8
13
11
9
10
16 15 14
2
6
12
The table that follows is a numbered descripon of the parts of the TX6160 radio, as labeled in the
diagram above.
Label No. Descripon Label No. Descripon
1 Antenna 9 Microphone
2 Scan/Memory/LED Torch Key 10 Accessory Jack
3 PTT (Push-to-talk) Switch 11 Belt Clip
4 Squelch/Silent/Keylock Switch 12 Baery
5 Indicator LED 13 LCD Screen
6 Lanyard Mount 14 Channel Up Key
7 On/O Switch and Volume Control 15 Menu/Funcon Key
8 Speaker 16 Channel Down Key
The table that follows is a numbered description of the parts of the TX6160 radio, as labeled in the
diagram above.
Label No. Description Label No. Description
1 Antenna 9 Microphone
2 Scan/Memory/LED Torch Key 10 Accessory Jack
3 PTT (Push-to-talk) Switch 11 Belt Clip
4 Squelch/Silent/Keylock Switch 12 Battery
5 Indicator LED 13 LCD Screen
6 Lanyard Mount 14 Channel Up Key
7 On/O Switch and Volume Control 15 Menu/Function Key
8 Speaker 16 Channel Down Key
