TX6160 INSTRUCTION MANUAL
SPECIFICATIONS
GENERAL
Type Description
Frequency Range 476.425 – 477.4125 MHz
Channel Spacing 12.5 kHz
No of Channels 80, (75 voice, 2 telemetry RX only, 3 for future use).
CTCSS Codes 50
DCS Codes 104
Dimensions (W x H x D): 59 mm x 102 mm x 35 mm (without antenna and battery pack)
Complies with AS/NZS 4365: 2011
POWER SUPPLY
Type Description
Power Source Li-ion rechargeable – 7.4V DC, 2600 mA
Operating Time
Low Power: Up to 30 hrs, High Power: Up to 18 hrs
(Transmit 5%, Receive 5%, Standby 90%)
RECEIVER
Type Description
Usable Sensitivity: -121 dBm
Maximum Audio Output: >0.5 watt max. (8 Ohm)
Modulation Distortion: <5% (1 kHz 70%)
TRANSMITTER
Type Description
Transmit Power:
Hi: 5 watts
Lo: 1 watt
Note: Specications are typical unless otherwise indicated and may be subject to change without notice or
obligation.
