go-e Gemini flex User Manual

1212
Product specications
Gemini ex 11 kW Gemini ex 22 kW
Dimensions Approx. 15.5 x 26 x 11 cm
Weight 1.63 kg 1.82 kg
Connection cable
30 cm + plug, 5 x 2.5 mm²
(type H07BQ-F)
30 cm + plug, 5 x 6 mm²
(type H07BQ-F)
Connection Single-phase or three-phase
Rated voltage 230 V / 240 V (single-phase) / 400 V / 415 V (three-phase)
Norminal frequency 50 Hz
Power grid types TT / TN / IT
Standby power 3.1 W (LEDs dark) to 5.2 W (LEDs bright)
RFID 13.56 MHz
WiFi 802.11b/g/n 2.4 GHz / frequency band 2412-2472 Mhz
Permissible ambient conditions
Gemini ex 11 kW Gemini ex 22 kW
Installation site
Indoors and outdoors,
without direct sunlight
Operating temperature -25 °C to +40 °C
Storage temperature -40 °C to +85 °C
Average temperature in hours Maximum 35 °C
Altitude Maximum 2,000 m above sea level
Relative humidity Not more than 95 % (non-condensing)
Impact resistance IK08
Charging capacity
Gemini ex 11 kW Gemini ex 22 kW
Maximum charging power
11 kW
(16 A, 3-phase)
22 kW
(32 A, 3-phase)
Ampere and status display Readable via LED ring and app
By button and app
Adjusting charging power
Via charging current in steps of 1
ampere between
6 A and 16 A
Via charging current in steps of 1
ampere between
6 A and 32 A
7. Technical data

go-e Gemini flex Specifications

General

Connector Type	Type 2
Product Type	Wallbox
RFID	Yes
MID Meter	Yes
Protection Class	IP54
Connectivity	Ethernet
Compatibility	All EVs with Type 2 connector
Input Voltage	400 V AC
Output Voltage	400 V AC
Dimensions	350 x 220 x 110 mm
