Gocycle G3 - Page 22

Gocycle
®
Owner’s Manual for G3, March 2016
© Karbon Kinetics Limited. All Rights Reserved. 18
4.3.2 Handlebar Height Adjustment
Undo and remove the handlebar stem bolt
using a Torx tool, as shown.
Lift the rubber dust cover to expose the
lower position.
Note! Hole “B. Upper position” denotes the
maximum height of the handlebar stem.
A. Lower
position
B. Upper
position
